Customizable PP Strapping Die with High-Quality Die Steel and ±0.05mm Tolerance for 5-19mm Widths

Customizable PP Strapping Die with High-Quality Die Steel and ±0.05mm Tolerance for 5-19mm Widths
Customizable PP Strapping Die with High-Quality Die Steel and ±0.05mm Tolerance for 5-19mm Widths

Großes Bild :  Customizable PP Strapping Die with High-Quality Die Steel and ±0.05mm Tolerance for 5-19mm Widths

Produktdetails:
Herkunftsort: China
Markenname: CHUQI
Modellnummer: CQ-SPP120-6
Zahlung und Versand AGB:
Min Bestellmenge: 1 SATZ
Verpackung Informationen: HOLZKISTE
Lieferzeit: 60 TAGE
Zahlungsbedingungen: T/T
Versorgungsmaterial-Fähigkeit: 10 Sätze
Kontakt

Customizable PP Strapping Die with High-Quality Die Steel and ±0.05mm Tolerance for 5-19mm Widths

Beschreibung
Standardmodus: 6 Stränge × 5–13,5 mm Optionaler Modus: 4 Stränge × 13,5–19 mm
Toleranz: ±0,05 mm Sterben Material: Hochwertig sterben Sie Stahl
Umstellung Zeit: 1-2 Stunden Anpassung: Nicht standardmäßig verfügbar
Flexibilität: Hoch

Customizable Die for Widths 5-19mm (6 Straps) or 13.5-19mm (4 Straps)
Product Introduction

Different customers have varying width requirements for PP strapping, ranging from narrow (5mm) to wide (19mm). The standard die of this production line enables synchronized production of 6 strands in the width range of 5-13.5mm. By replacing with an optional die, it can switch to synchronized production of 4 strands in the width range of 13.5-19mm.

This flexible die configuration allows one machine to cover a wider range of product specifications, meeting different order requirements. Additionally, we can customize dies according to special customer requirements (e.g., non-standard widths or special cross-sectional shapes), further expanding the production capability of the line.

Main Specifications
  • Standard mode: 6 synchronized strands, single strand width 5-13.5mm
  • Optional mode: 4 synchronized strands, single strand width 13.5-19mm
  • Dimensional consistency: ≤±0.05mm
  • Die material: High-quality die steel, precision machined
  • Customization capability: Non-standard specifications can be custom-made per customer drawings
Technical Parameters
Item Standard Mode Optional Mode
Synchronized strands 6 strands 4 strands
Single strand width range 5 - 13.5 mm 13.5 - 19 mm
Thickness range 0.3 - 1.0 mm 0.3 - 1.0 mm
Dimensional tolerance ≤ ±0.05 mm ≤ ±0.05 mm
Die change Standard included Optional
Custom dies Non-standard widths/sections available Available
Customer Questions & Answers
Q: How long does it take to switch from 6-strand mode to 4-strand mode?
A: With skilled operation, die change and adjustment take about 1-2 hours, including removing the original die, cleaning, installing the new die, centering, and temperature stabilization.
Q: When producing wide straps (e.g., 19mm) in 4-strand mode, does output decrease?
A: The total width in 4-strand mode is larger (4×19=76mm). Although the number of strands is reduced, the increased individual width allows the extrusion output to be fully utilized. Total capacity is close to that of narrow-strap production in 6-strand mode.
Q: What is the cost and lead time for a custom die?
A: Cost depends on die complexity and size, typically 1.5-3 times that of a standard die. Lead time is about 4-8 weeks, requiring final confirmed drawings or samples from the customer.

Größe und Tag:

Synchrone PP-Umreifungslinie,

Produktionslinie für PP-Umreifungsbänder,

Hochleistungs-PP-Umreifungsmaschine
